Mechatronic Unit Repair Kit (Audi 7 Speed DSG)
On all orders over $99.00
7 days money back gutarantee
We support 24/24h on day
Safe shopping guarantee
This printed circuit is located inside the transmission of the 7 Speed (OB5) Audi transmissions. When this part fails, it may result in a variety of faults listed below, which are a part of Audi TSB 2030477. To install this part, you need to drain the transmission, remove the DSG transmission pan, and remove the mechatronics unit. This will give you access to replace this part.
Faults listed in TSB
DTC P17D8 (Torque limitation because of clutch temperature) with symptom code 8040
DTC P0726 (RPM signal of engine control unit, implausible signal) with symptom code 7980
DTC P174B (Valve 4 in the sub-gearbox 1, electric fault) with symptom code 8027
DTC P174F (Valve 4 in the sub-gearbox 2, electric fault) with symptom code 8028
DTC P179C (Main pressure valve, electric fault) with symptom code 8029
DTC P179D (Coolant oil valve electrical fault) with symptom code 8030
DTC P174C (Partial transmission 1 valve 2 Electrical error ) with symptom code 8026
DTC P174A (Valve 3 in the sub-gearbox 1, electric fault) with symptom code 8939
DTC P174E (Valve 3 in the sub-gearbox 2, electric fault) with symptom code 8940
DTC P1740 (Clutch temperature monitoring) with symptom code 8031
Previous Version
0B5398009A
0B5398009B
0B5398009C
0B5398009D
0B5398009E
