If you need to perform coding on your LED tail lights and don't have a VAG COM already check out the OBDeleven which is a much less expensive alternative.

OBDeleven for MK7 LED Taillight Coding



Coding option 1

OBDeleven One Touch Coding for our DAP MK7 LED Tail Light Harness found HERE (100 credits are required for this coding 100 credits = €11.99)

OBDeleven MK7 DAP Taillight coding

PLEASE NOTE:  This coding was performed on our MK7 GTI S model.  Coding may vary depending on model.  Please know that while we do produces harness that must be used for these LED Lights to work in the way displayed, we cannot offer support if the coding below does not work on your vehicle.  If this coding does not work you should consult with a VW specialist shop who can help perform this.  E-Golf may have a "soft code" for a sidemarker bulb out that does not display in cluster after coding.



After completing the installation of our harness (video below) you can begin the coding using a VAG-COM or OBDeleven


[embed]https://www.youtube.com/watch?v=mnTI9je9fh0[/embed]







Once the coding is complete, this is how they should operate:



[embed]https://www.youtube.com/watch?v=-yTBA-JH0O8[/embed]






 Coding option 2
This can be done with a VAGCOM or OBDeleven and is the manual method for LED Tail Light Coding

Begin by opening the "Security Access" screen.


 photo 1_zpsacc1c2b3.png



Enter in the code (31347) to unlock the adaptation channels.

 photo 2_zps196eb2b5.png


Click "Ok"

 photo 3_zps4332c1d5.png


Open Adaptation, and begin on the channel "(1)-Leuchte20BR LA71-Lasttyp 20", it should be approximately 3/4 of the way down the list.

 photo 4_zps58a3d91b.png


Change the coding from "14 - kombinierte Blink - Bremsleuchten" to "34 - LED Bremsleuchten", Click "Do it!"

 photo 5_zpsc0722663.png


Click "Yes"

 photo 6_zpsb70ec832.png


Click "Ok"

 photo 7_zpsf62944ff.png


This is how it should look after clicking "Ok"

 photo 8_zps01fc7bfc.png


Select "(5)-Leuchte20BR LA71-Lichtfunktion B 20"

 photo 9_zpsfaf470e3.png


Change the New value to "not active"

 photo 10_zps30409b43.png


Click "Yes"

 photo 11_zps9a20aa11.png


Click "Ok"

 photo 12_zps6af20912.png


What the correct coding should look like.

 photo 13_zpsc212dc26.png


Select the next channel "(8)-Leuchte20BR LA71-Lichtfunktion C 20"

 photo 14_zps1b5d1896.png


Change the New value to "not active"

 photo 15_zpse326504e.png


Click "Yes"

 photo 16_zps492c2389.png


Click "Ok"

 photo 17_zps5cae71c0.png


What the correct coding looks like.

 photo 18_zpsa0aec561.png


Select the next Channel "(1)-Leuchte21BR RC8-Lasttyp 21"

 photo 19_zps6f6b798b.png


Change the New value to "34 - LED Bremsleuchten"

 photo 20_zpsefda0841.png


Click "Yes"

 photo 21_zps800187e8.png


Click "Ok"

 photo 22_zpsee0488a4.png


Correct coding.

 photo 23_zps9ee0d5e5.png


Select the next Channel "(5)-Leuchte21BR RC8-Lichtfunktion B 21

 photo 24_zpsbc63fc1b.png


Change the New value to "not active"

 photo 25_zps1575347b.png


Click "Yes"

 photo 26_zps17b74ebd.png


Click "Ok"

 photo 27_zpsdba4420e.png


Select the next Channel "(8)-Leuchte21BR RC8-Lichtfunktion C21"

 photo 28_zps3edbe3cb.png


Change the New value to "not active"

 photo 29_zpsf0dbb3c0.png


Click "Yes"

 photo 30_zps3970456c.png


Click "Ok"

 photo 31_zpsa01ba586.png


Correct coding

 photo 32_zps0b9ac397.png


Select the next Channel "(1)-Leuchte23SL HLC10-Lasttyp23"

 photo 33_zps1bc3ce4d.png


Change the New value to "33 - LED-Modul Blinkleuchten"

 photo 34_zpsf1b72f00.png


Click "Yes"

 photo 35_zpsaa6e33dd.png


Click "Ok"

 photo 36_zps822f1d9b.png


Correct coding.

 photo 37_zps3e7a44d4.png


Select the next Channel "(4)-Leuchte23SL HLC10-Lichtfunktion A 23"

 photo 38_zpsb6e45ff3.png


Change the New value to "not active"

 photo 39_zps523ac4bc.png


Click "Yes"

 photo 40_zps5f805cb3.png


Click "Ok"

 photo 41_zps0101f6e0.png


Correct coding.

 photo 42_zpsc2b50d6e.png

Select the next Channel to change: "(8)-Leuchte23SL HLC10-Lichtfunktion C 23"


Change New value to "Blinken links Hellaphase"


Click Yes


Click OK


Correct Coding


Select the next Channel to change: "(10)-Leuchte23SL HLC10-Dimmwert CD 23"

 photo 43_zps56564a50.png


Change the New Value to "127"

 photo 44_zps63e09afa.png


Click "Yes"

 photo 45_zps668ee44f.png


Click "Ok"

 photo 46_zps8fd9f168.png


Correct coding.

 photo 47_zps03c04bcc.png


Select the next Channel to change : "(1)-Leuchte24SL HRA65-Lasttyp 24"

 photo 48_zps3eac72ae.png


Change the New value to "33 - LED-Modul Blinkleuchten"

 photo 49_zpscf8e7305.png


Click "Yes"

 photo 50_zps5fb6b798.png


Click "Ok"

 photo 51_zpsd346332a.png


Correct coding.

 photo 52_zpsd85bed46.png


Select the next Channel to change: "(4)-Leuchte24SL HRA65-Lichtfunktion A24"

 photo 53_zps387de75a.png


Change the New value to "not active"

 photo 54_zps9eaaecfd.png


Click "Yes"

 photo 55_zpsa633757e.png


Click "Ok"

 photo 56_zps0b60dd93.png


Correct coding.

 photo 57_zpscbf5969a.png


Select the next Channel to change: "(8)-Leuchte24 SL HRA65-Lichtfunktion C 24"

 photo 58_zps148e04d8.png


Change the New value to "Blinken rechts Hellaphase"

 photo 59_zps2791e15c.png


Click "Yes"

 photo 60_zpsd1e08e55.png


Click "Ok"

 photo 61_zpsc7f839d9.png


Select the next Channel to change "(10)-Leuchte24SL HRA65-Dimmwert CD 24"

 photo 62_zpsec236488.png


Enter "127" as the New value.

 photo 63_zpse6bc786d.png


Select "Yes"

 photo 64_zps39ac0bb4.png


Select "Ok"

 photo 65_zps6d8546f0.png


Correct coding:

 photo 66_zps0a15fc58.png


Once all of the coding is completed here is how they should operate.
