Volkswagen Atlas 2.0T Water Pump – Locate Problems, How to, and Tips



The Volkswagen Atlas, produced in 2018, 2019, 2020, 2021, 2022, 2023, and 2024 offer a 2.0T turbocharged four-cylinder engine paired with an eight-speed automatic transmission. It is available with both front-wheel drive (FWD) and Volkswagen's 4Motion all-wheel drive (AWD) drivetrain options. In 2020, the Atlas received a facelift with updated styling, retaining the 2.0T engine.

The water pump on the 2.0T engine plays a crucial role in the cooling system, circulating coolant to maintain optimal engine temperature. Issues like leaks or failure are common with the 2.0T engine water pump, requiring replacement to prevent overheating, or a large leak.



Purchase a 2018 2.0t VW Atlas Water Pump

Purchase a 2019 2.0t VW Atlas Water Pump

Purchase a 2020 2.0t VW Atlas Water Pump

Purchase a 2021 2.0t VW Atlas Water Pump

Purchase a 2022 2.0t VW Atlas Water Pump

Purchase a 2023 2.0t VW Atlas Water Pump

Purchase a 2024 2.0t VW Atlas Water Pump



2.0t VW Atlas Water Pump Problems

The water pump on the 2.0t Atlas is located on the front side of the engine, below the intake manifold.  To perform a visual inspection, you should remove the lower engine shield and follow the radiator hoses up to locate the water pump/thermostat housing.

Your Atlas Water pump is belt driven by the balance shaft and consists of the thermostat housing (generally what leaks), and the water pump, which is mounted to the thermostat housing.  Your Atlas uses an electromechanical thermostat, to control coolant flow, and while this can fail it’s not the most common failure.  If you have a failure the water pump and thermostat housing should be replaced together.

  1. Coolant Leaks
    The most common way that the 2.0t Atlas water pump fails is due to leaks.  This will generally happen on the thermostat housing where it meets the engine block.  This also may happen where the water pump and thermostat are bolted together.
  2. Fault Codes

Leaks are a more common failure, but it is possible to have a check engine light, and fault codes related to the thermostat housing.  The fault below is the most likely.

P00B7: Low coolant flow/performance

  1. Overheating
    Overheating is pretty rare with these water pump failures, but its important to note if you run your vehicle low on coolant this is a possible outcome.  If your Atlas temp gauge moves past the middle you should not continue to run the vehicle, as driving an overheating vehicle will likely damage the engine.



How to Replace your 2.0t Atlas Water Pump

The Atlas water pump is something you might consider to DIY if you have a reasonably high level of skill and tools.  To replace this part you will want to remove the intake manifold to have visibility to the pump.  When installing this you will want to replace the Thermostat housing, water pump, union between the thermostat and oil cooler, the belt and the reverse thread bolt that holds the balance shaft drive gear on.  Some may opt to not replace the drive belt as this can be tough to get the pulley off.  The belt does not have a service interval so it is not required to replace.

  • We have a DIY video on how to replace the thermostat/waterpump on another VW model, which uses the exact same part. This may have some variation on your Atlas but will be very similar. VIDEO



Maintaining your VW Atlas's water pump is key to keeping your engine running smoothly and avoiding costly repairs. Regular visual inspections and addressing any signs of leaks early can prevent more serious problems, like overheating. If you experience any of the common symptoms, such as coolant leaks or fault codes, it's crucial to address them quickly. Replacing the water pump and thermostat housing together is often the best course of action.

If you're a confident DIYer, its possible to save money by replacing the water pump yourself. Make sure you have the necessary tools and skills to complete the job properly.

Proper maintenance and timely intervention can keep your 2.0T Atlas performing well for years to come, ensuring reliability and safety for all your adventures. If you're unsure about tackling this repair, consider seeking help from a qualified mechanic to keep your Atlas in top condition.
